FHM2 Series Optical Multimeter Data storage up to 999 items and 0.01db display precision

  • FHM2 Series Optical Multimeter Data storage up to 999 items and 0.01db display precision
  • FHM2 Series Optical Multimeter Data storage up to 999 items and 0.01db display precision
  • FHM2 Series Optical Multimeter Data storage up to 999 items and 0.01db display precision
  • FHM2 Series Optical Multimeter Data storage up to 999 items and 0.01db display precision
Place of Origin China
Brand Name OMC or OEM
Certification ROHS and ISO
Model Number FHM2 Series Optical Multimeter
Minimum Order Quantity 20
Price Negotiation
Packaging Details Inner PE Bag and carton
Delivery Time 5 - 8 work days
Payment Terms L/C, T/T, Western Union
Supply Ability 1000/pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type FHM2B01 Calibration Wavelength 850/1300/1310/1490/1550/1625nm
Connector Interchangeable FC/SC (ST Optional) Data Storage 999 Items
Ref.Value Yes Display Units DB/dBm/mW/uW
Display Precision 0.01dB Accuracy ±5%±1nW
Leave a Message
Product Description

Deacription:

FHM2 Series Optical Multimeter Data storage up to 999 items and 0.01db display precision 0
FHM2 Series Optical Multimeter'


OMC provides high precision optical multimeter. FHM2 Series Optical Multimeter integrates a stable optical laser source and a precise optical power meter.

The optical laser source unit launches the laser whose wavelengths are at 1310/1490/1550nm or 1310/1550nm (according to the model). The optical power meter unit can recognize the wavelength automatically. FHM2 Series Optical Multimeter offers a large storage capacity; With the assorted software, user can generate a report or manage the test report easily.





Features:


  • Auto wavelength recognition



  • Data storage up to 999 items



  • USB interface and PC associated software available

Specification:

TypeFHM2A01FHM2B01
Power Meter Parameters:
Calibration Wavelength850/1300/1310/1490/1550/1625nm
Connectorinterchangeable FC/SC (ST optional)
Data Storage999 items
Ref.ValueYes
Display UnitsdB/dBm/mW/uW
Display Precision0.01dB
Accuracy±5%±1nW
Wavelength Recognition1310/1490/1550 (input power≥-40dBm)
Tone Detection270Hz/1KHz/2KHz (input power≥-40dBm)
Measuring Range-70 to +10dBm-50 to +26dBm
Laser Source Parameters:
Output Wavelength1310/1550nm
Connectorfixed FC/PC (interchangeable FC/SC/ST customized)
Modulation Frequencies270Hz/1KHz/2KHz
Output Power-5dBm±0.5dB
Stability Long-term (8h)±0.1dB@1310/1550nm
Stability Short-term(15min)±0.05dB@1310/1550nm
Wavelength Recognizing CodeYes
Auto Power offYes
General Parameters:
Power Supply2pcs*NiHM 1.2V, 2000mAh; AC/DC Adapter
PC InterfaceUSB
Battery Life>100 hours (laser off)
Storage Temperature-20℃~+70℃
Operating Temperature-10℃~+50℃
Relative Humidity<90% (Non-condensing)

TypeFHM2A02FHM2B02
Power Meter Parameters:
Calibration Wavelength850/1300/1310/1490/1550/1625nm
Connectorinterchangeable FC/SC (ST optional)
Data Storage999 items
Ref.ValueYes
Display UnitsdB/dBm/mW/uW
Display Precision0.01dB
Accuracy±5%±1nW
Wavelength Recognition1310/1490/1550 (input power≥-40dBm)
Tone Detection270Hz/1KHz/2KHz (input power≥-40dBm)
Measuring Range-70 to +10dBm-50 to +26dBm
Laser Source Parameters:
Output Wavelength1310/1490/1550nm
ConnectorFC/PC, SC/PC
Modulation Frequencies270Hz/1KHz/2KHz
Output Power0dBm±0.5dB
Stability Long-term (8h)±0.1dB@1310/1550nm; ±0.2dB@1490nm
Stability Short-term(15min)±0.05dB@1310/1550nm; ±0.1dB@1490nm




Wavelength Recognizing CodeYes
Auto Power offYes
General Parameters:
Power Supply2pcs*NiHM 1.2V, 2000mAh; AC/DC Adaptor
PC InterfaceUSB
Battery Life>100 hours (laser off)
Storage Temperature-20℃~+70℃
Operating Temperature-10℃~+50℃
Relative Humidity<90% (Non-condensing)
Dimension168mmL×76mmW×43mmH
Weight310g
Standard Accessories:

FC adapter, SC adapter, 2*rechargeable batteries, AC/DC adapter, 3*ceramic sleeves, USB cable,

carrying bag, CD disk, user manual, test report

Optional Accessories:
ST adapter (model: N000500), 1.25mm PD adapter, 2.5mm PD adapter
Customization:
APC
